12 Series: Non-Stacking Spacer, #4 screw
Stacking/Non-Stacking Spacers
- Non-stacking type
- For .062 Thick PCB
- Insulates screws
- Fastens securely in place; maintains position during screw replacement/removal
- Screw size: #4 (M3)
- Color: Natural
- Packaging: 1000/bag
- Material: Nylon 66
- RoHS Compliant
Item # |
Material Code |
Mounting Hole Diameter |
Dim. - L |
Dim. - W1 |
Dim. - W2 |
Request Quote/Sample |
|---|---|---|---|---|---|---|
| 07-12-20 07-12-20/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .126 (3.2) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-30 07-12-30/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .189 (4.8) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-40 07-12-40/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .252 (6.4) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-50 07-12-50/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .311 (7.9) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-60 07-12-60/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .374 (9.5) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-70 07-12-70/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .437 (11.1) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-80 07-12-80/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .500 (12.7) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-100 07-12-100/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .626 (15.9) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-120 07-12-120/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .750 (19.0) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-140 07-12-140/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .875 (22.2) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-160 07-12-160/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-2 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A 1.000 (25.4) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-20-X 07-12-20-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .126 (3.2) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-30-X 07-12-30-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .189 (4.8) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-40-X 07-12-40-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .252 (6.4) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-50-X 07-12-50-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .311 (7.9) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-60-X 07-12-60-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .374 (9.5) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-70-X 07-12-70-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .437 (11.1) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-80-X 07-12-80-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .500 (12.7) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-100-X 07-12-100-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .626 (15.9) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-120-X 07-12-120-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .750 (19.0) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-140-X 07-12-140-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A .875 (22.2) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
| 07-12-160-X 07-12-160-X/Asset/07-12-17-stacking-spacer.png | Material Code N/A UL94V-0 | Mounting Hole Diameter N/A .187 ± .003 (4.7 ± .08) inches (mm) | Dim. - L N/A 1.000 (25.4) inches (mm) | Dim. - W1 N/A .125 (3.1) inches (mm) | Dim. - W2 N/A .260 (6.6) inches (mm) | Request Quote/Sample |
