16 Series: Coated Flexible (Screw) Clip
Screw Mount Style
- Affix with screw to base
- Insulated
- Accommodates a wide range of bundle diameters
- Color: Black
- Packaging: 500/bag
- Material: Clip - .5t Zinc Plated Steel, Coating - Soft PVC
Item # |
Dim. - ID |
Dim. - OD |
Dim. - L1 |
Dim. - L2 |
Dim. - W |
Dim. - T1 |
Dim. - T2 |
Request Quote/Sample |
|---|---|---|---|---|---|---|---|---|
| 03-16-10 03-16-10/Asset/03-16-Series-Coated-Flexible--Screw--Clip.png | Dim. - ID N/A .130 (3.3) inches (mm) | Dim. - OD N/A .236 (6.0) inches (mm) | Dim. - L1 N/A 1.77 (45.0) inches (mm) | Dim. - L2 N/A 2.13 (54.0) inches (mm) | Dim. - W N/A .138 (3.5) inches (mm) | Dim. - T1 N/A >.008 (.2) inches (mm) | Dim. - T2 N/A .039 ± .020 (1.0 ± .5) inches (mm) | Request Quote/Sample |
| 03-16-20 03-16-20/Asset/03-16-Series-Coated-Flexible--Screw--Clip.png | Dim. - ID N/A .130 (3.3) inches (mm) | Dim. - OD N/A .315 (8.0) inches (mm) | Dim. - L1 N/A 1.18 (30.0) inches (mm) | Dim. - L2 N/A 1.61 (41.0) inches (mm) | Dim. - W N/A .138 (3.5) inches (mm) | Dim. - T1 N/A >.008 (.2) inches (mm) | Dim. - T2 N/A .039 ± .020 (1.0 ± .5) inches (mm) | Request Quote/Sample |
| 03-16-30 03-16-30/Asset/03-16-Series-Coated-Flexible--Screw--Clip.png | Dim. - ID N/A .130 (3.3) inches (mm) | Dim. - OD N/A .315 (8.0) inches (mm) | Dim. - L1 N/A 1.77 (45.0) inches (mm) | Dim. - L2 N/A 2.20 (56.0) inches (mm) | Dim. - W N/A .138 (3.5) inches (mm) | Dim. - T1 N/A >.008 (.2) inches (mm) | Dim. - T2 N/A .039 ± .020 (1.0 ± .5) inches (mm) | Request Quote/Sample |
| 03-16-40 03-16-40/Asset/03-16-Series-Coated-Flexible--Screw--Clip.png | Dim. - ID N/A .130 (3.3) inches (mm) | Dim. - OD N/A .315 (8.0) inches (mm) | Dim. - L1 N/A 2.17 (55.0) inches (mm) | Dim. - L2 N/A 2.60 (66.0) inches (mm) | Dim. - W N/A .177 (4.5) inches (mm) | Dim. - T1 N/A >.008 (.2) inches (mm) | Dim. - T2 N/A .039 ± .020 (1.0 ± .5) inches (mm) | Request Quote/Sample |
| 03-16-50 03-16-50/Asset/03-16-Series-Coated-Flexible--Screw--Clip.png | Dim. - ID N/A .173 (4.4) inches (mm) | Dim. - OD N/A .315 (8.0) inches (mm) | Dim. - L1 N/A 1.77 (45.0) inches (mm) | Dim. - L2 N/A 2.20 (56.0) inches (mm) | Dim. - W N/A .177 (4.5) inches (mm) | Dim. - T1 N/A >.008 (.2) inches (mm) | Dim. - T2 N/A .039 ± .020 (1.0 ± .5) inches (mm) | Request Quote/Sample |
| 03-16-60 03-16-60/Asset/03-16-Series-Coated-Flexible--Screw--Clip.png | Dim. - ID N/A .173 (4.4) inches (mm) | Dim. - OD N/A .315 (8.0) inches (mm) | Dim. - L1 N/A 2.17 (55.0) inches (mm) | Dim. - L2 N/A 2.60 (66.0) inches (mm) | Dim. - W N/A .177 (4.5) inches (mm) | Dim. - T1 N/A >.008 (.2) inches (mm) | Dim. - T2 N/A .039 ± .020 (1.0 ± .5) inches (mm) | Request Quote/Sample |
| 03-16-70 03-16-70/Asset/03-16-Series-Coated-Flexible--Screw--Clip.png | Dim. - ID N/A .173 (4.4) inches (mm) | Dim. - OD N/A .315 (8.0) inches (mm) | Dim. - L1 N/A 2.56 (65.0) inches (mm) | Dim. - L2 N/A 2.99 (76.0) inches (mm) | Dim. - W N/A .177 (4.5) inches (mm) | Dim. - T1 N/A >.008 (.2) inches (mm) | Dim. - T2 N/A .039 ± .020 (1.0 ± .5) inches (mm) | Request Quote/Sample |
| 03-16-80 03-16-80/Asset/03-16-Series-Coated-Flexible--Screw--Clip.png | Dim. - ID N/A .130 (3.3) inches (mm) | Dim. - OD N/A .315 (8.0) inches (mm) | Dim. - L1 N/A 1.93 (49.0) inches (mm) | Dim. - L2 N/A 2.36 (60.0) inches (mm) | Dim. - W N/A .118 (3.0) inches (mm) | Dim. - T1 N/A >.008 (.2) inches (mm) | Dim. - T2 N/A .039 ± .020 (1.0 ± .5) inches (mm) | Request Quote/Sample |
| 03-16-90 03-16-90/Asset/03-16-Series-Coated-Flexible--Screw--Clip.png | Dim. - ID N/A .138 (3.5) inches (mm) | Dim. - OD N/A .315 (8.0) inches (mm) | Dim. - L1 N/A .886 (22.5) inches (mm) | Dim. - L2 N/A 1.36 (34.5) inches (mm) | Dim. - W N/A .197 (5.0) inches (mm) | Dim. - T1 N/A >.008 (.2) inches (mm) | Dim. - T2 N/A .039 ± .020 (1.0 ± .5) inches (mm) | Request Quote/Sample |
